E introduction series 31003200 high output pressure transducers and transmitters are fitted with an asic. 3100 series compact high pressure oem pressure transmitter electrical connectors packard metri pack code 01 g 14 ext code 04 716 20 unf with 37 flare code 1j o ring code 02 14 18 npt code 08 18 27 npt code 05 g 14a integral face seal code 2t m12x15 hp metal washer seal code ig 716schraeder 125 11 14 7 128 111 1444.
Download Tps Wiring Diagram 2005 Envoy
Gems 3100 series wiring diagram. The manufacturing process for the 3100 series includes the latest automated equipment producing the most consistent and best price to performance sensor on the market today. Series 3000 3100 page 1. Isi gessesorso for os rre iforio 3100 3200 series p1of5 20 aug 19 3100 series and 3200 heavy duty series compact oem pressure transmitters exceptional long term stability 0 100 psi to 0 30000 psi ranges 0 7 bar to 0 2200 bar high proof pressures with all stainless steel wetted parts. For oems that need consistent high levels of performance reliability and stability the. 3200 series transmitters feature thicker diaphragms and a pressure restrictor to withstand the rigors of cavitations or extreme pressure spikes. 3100 series and 3200 heavy duty series.
Compact oem pressure transmitters 0 7 bar to 0 2200 bar ranges 0100 psi to 0 30000 psi high proof pressures broad choice of outputs rohs compliant. Isi essesorso for os rre iforio 3100 3200 series p1of5 9 jul 19 3100 series and 3200 heavy duty series compact oem pressure transmitters exceptional long term stability 0 100 psi to 0 30000 psi ranges 0 7 bar to 0 2200 bar high proof pressures with all stainless steel wetted parts. Series 31003200 compact high pressure oem pressure transmitter instruction bulletin no. Installation instructions index and operator handing the km series 30003100 operators have been carefully designed built and tested to provide years of service. Inch mm 3100 3200 series p3of5 26 oct 16 wiring diagram power supply. Gems sensors controls operating installation instructions 31xx 32xx series please read carefully before installing part number.
31003200 series pressure transducers feature all stainless steel wetted parts a broad selection of electrical and pressure connections and electrical outputs to allow stock configurations suitable for most applications without modification. The life of these operator packages is directly related to how carefully the installation is accomplished. Additionally 3200 series transmitters feature thicker diaphragms and a pressure restrictor to withstand the rigours of cavitations or extreme pressure spikes delivering. B important note all gems pressure level flow products are designed and manufactured in accordance with sound engi neering practice as defined by the pressure equipment directive 9723ec.
