The mr601tex gives an earlier response to tf5 fires than the mr601 due to its thermal circuit detecting the heat generated by this test of fire and the mr601tex being enhanced. 24 vac signal stat light will go on and off with 24 vac signal.
Zettler Product Catalogue Minerva Mx4000 2 5 For
Tyco mr601tex wiring diagram. Irrigation system control unit user manuals operating guides specifications. If you are in possession of any ho train enginecar assembly diagrams brochure or catalog that are not listed within this site please contact me about posting them here in this section. Model ho train reference and resource website. Alternative wiring 24 vac powered input signal h n remove jumper. Minerva mr601tex high performance optical smoke detector these detectors react to the whole range of fire products from slow smouldering fires producing visible particles to open flaming fires producing large numbers of very hot smaller sized aerosols. Mr601tex intrinsically safe enhanced optical smoke detector product application and design information 1.
The tyco md601ex 516052051y is an is heat detector that uses two networked thermistors in a bridge configuration to provide a fast response that depends both on absolute temperature and rate of rise of temperature. 7 repeaters can be attached to the control panels 2 wire remote bus. Do not connect power to n and h terminals. And is intended for two wire operation with the majority of control equipment currently manufactured by the company. Introduction the mr601tex intrinsically safe high performance optical smoke detector forms part of the m600ex series of plug in detectors for ceiling mounting. Flame detector 801phex is.
It combines optical and heat detector technology to detect clear burning fire products which hitherto could only be easily detected by ion. Ii 1 g cenelec code. Tyco expert graphics txg 41 tli800en network interface module 44 mxnet 46 mx minerva bridge 47. 801f mx flame detector 801fex mx is. When using alternative wiring diagram the boiler oper ating controls zc terminal will see the load of the circulators. View download of more than 253 tyco pdf user manuals service manuals operating guides.
Power light will always be off. Opticalheat detector 801chex is. Two repeaters are mains driven with internal mains psu batteries and two require an external 24vdc. Heat detector 802sb mx low power sounder base lpsb3000 loop powered sounder. Coheat tyco 801hex is. The tyco md601ex can be used in areas where smoke detectors are unsuitable due to smoke dust or other environmental conditions.
The mr601tex is designed to respond to the mandatory tests tf2 to tf5 as required by bs5445 pt 7. Eex ia iic t5 under atex certificate number bas01atex1134x. Intrinsic safety the detectors are designed to comply with en 50 014 and en50 020 for intrinsically safe apparatus. The detector plugs into the 5bex 5 universal is base and is intended for two wire. The mr601tex detector is designed to comply with en 50 014 and en 50 020 for intrinsically safe apparatus and is certified.
