The diagram below represents the schematic diagram for a spst rocker switch. I bought a 3 prong spst illuminated switch at radioshack its rated for 10a at 125vac.
Wiring A Diagram Cqc 16a 250vac T125 55 Kcd3 Rocker Switch
Kcd3 switch wiring diagram. Im building an adjustable regulator 12 25v at 5a and want if possible an illuminated onoff switch. Now that you have an idea how rocker switches are constructed internally lets go over the wiring diagram so that you will now how to connect a rocker switch to a circuit. Home new products. Rocker switch wiring diagram. In this video we are giving a tutorial on how to wire a rocker switch with led 6 and 7 pin wiring diagrams to control a linear actuator as well as showing how exactly a rocker switch works. This switch will be connected to the mains likely in between the fuse and transformer.
When wiring this switch you can choose if youd like to illuminate it because of the independent lamp attached to terminals 8 and 7. Search please input the product keywords. 3 way switched outlet wiring. 3 buttons rocker switch kcd3 303. The source is at the sw1 where the hot is connected to. The wiring diagram to the right will show how to wire and power this 12v 20amp on off on 3 way carling contura rocker switch.
This circuit is wired the same way as the 3 way lights at this link. Or these terminals can be ignored for non backlit switch banks. As shown below rocker switches have 3 electrical connections. In this diagram two 3 way switches control a wall receptacle outlet that may be used to control a lamp from two entrances to a room. Three wire cable runs between the switches and the outlet.
