9xxxxxlekxxxxx follow the wiring diagram on the reader. Install reader to backplate.
Swh Bridge Open Options
Istar edge wiring diagram. It is two wire half duplex rs 485. To connect ac power. The istar ultra will supply 0 to 30 vdc depending on the input supply. Ac power the istar pro input power rating is 100 240 vac 23a max 47 63 hz. Istar ex istar edge ccure 9000 controller capacity istar pro 64 mb istar pro 128 mb firmware version v40 or higher v40 or higher number of personnel records with one clearance one cardperson ten digit cards 500000 500000 number of personnel records with ten clearances one cardperson ten digit cards 295000 500000. Previous iclass readers had reversed rs 485 wiring p2 7 p2 6 a b.
Page 4 this section describes the power requirements for the istar pro. Notice that the jumper is in the wet position. When upgrading to an iclass se reader ensure proper connections. Wet relay wiring figure 6 12 on page 6 14 shows wet wiring for a normal no latch. Rs 485 reader bus rs 485 is the reader bus connection to the apc or istar. Note when the wiring gauge is too small or the wiring runs are too long the yellow led drive oscillation can cause cross talk and result in misreads.
The suite of istar door controllers provides powerful network ready solutions for enterprise wide access control. Its optional power over ethernet poe module provides ample power for two doors and allows istar edge to leverage existing network infrastructure to reduce installation. Its optional power over ethernet poe module provides ample power for two doors and allows istar edge to leverage. Wet wiring for a magnetic lock. Turn on power test card. For 5 meter pigtail readers pn.
This chapter provides the information you need to set up an istar or apc installation that includes rm 4 hardware. Istar edge is a powerful ip edge access control device that provides a strong feature set to secure any door. Available in one two or four reader models to provide the right size controller for your specific application. Connect tx rx to pin 2 and connect tx rx to pin 3. Installing the rm 4 this chapter provides detailed rm 4 component diagrams overviews the installation procedure and provides detailed installation instructions. Istar edge is a powerful ip edge access control device that provides a strong feature set to secure any door.
Point to point wiring diagrams consult with the acp installation documentation. Available in one two or four reader models to provide the right size controller for your specific application. Notice that the gnd is used for common not the c pin. Gcm istar istar classic istar pro istar ex edge apc8x and apcl software house apc8x star coupler rm4 ad300 ad400 wiegand software house apc8x wpsc ad300 ad400 wiegand software house apcl rm4 ad300 ad400 wiegand. Photograph of istar pro acm. Photograph of istar pro gcm acm module figure 3.
The istar pro istar ultra and istar ultra se models are also available in space saving rack mount modelsbrbrp. Current is limited to 075 a. Featuring advanced encryption and backup communication paths the istar design is among the industrys most reliable and secure. The system current draw is 23a at 100vac or 11a max at 240vac 47 63hz.
