The devireg 530 series is a line of electronic thermostats used for control of indoor heating. The display screen is not easy to remove once it has been pressed into place.
Devireg 330 5 To 45 C Pdf Free Download
Devireg 330 wiring diagram. Contactors are required whenever the heating load exceeds the thermostats capacity of 15 amps. Bottom piece until all wiring connections to terminals are complete. The thermostat must be installed via an all pole disconnection switch. It is designed for installation into panel boards with an overall minimum height of 52mm as well as for din rail attachment. The devireg 530 is used for control of floor heating installations. Above floor level in a dual box 35mm² deep as mk 887 zic 220 240v at.
The devireg 531 is used for control of room heating installa tions. When wiring to a contactor the active output of the thermostat 1 is used to energise the coil on the. Devireg 330 is an electronic thermostat to be installed in electric cabinets with din rail attachment. Original gibson epiphone guitar bass wiring diagrams listed by guitar model. It is designed for installation into panel boards with an overall minimum height of 52mm as well as for din rail attachment. The devireg 330 is an electronic thermostat with a 5 temperature set back.
Contactor connection diagram for a devireg 330 the devireg 130 series thermostats have a limited switching capacity. The thermostat is equipped with a floor sensor for control of the desired floor temperature. Do not press on the display screen when removing the front part. Wiring diagrams for the devimat system. Carcase wiring requirements for devimat upto 20m² for concrete 30m² for timber base floors using the devireg 550 controller thermostat connection devireg 550 controller mounted 15m. Devireg 330 must be placed after an external switch.
The deviregtm 330 must be mounted after an external switch or circuit breaker. The installation must be permanent. The thermostat must be attached to a vibration free surface. The temperature is lowered by 5ºc when clamps 3 and 6 are short circuited by means of an external switch see circuit diagram. Either a wire sensor or an external air sensor must be used to measure and control the. Page 10 devireg touch follow the steps below to mount the thermostat.
Used primarily for controlling a lower temperature range as by frost pro tection. Contactors or other objects producing strong electromagnetic fields must not be placed in the immediate vicinity of the. A room sensing unit is to be placed on an inner wall about. The deviregtm 330 is an electronic thermostat with a 5oc temperature set back.
