Connection diagrams cbc 100 1 2 cbc 150 1 2 dimensions all dimensions nominal unless otherwise specified. Cbc 801 1 115 vac input cbc 801 2 220240 vac input these controls indicate when the brake and clutch.
Warner Electric Cbc 801 1 Clutch Brake Control Relay
Cbc 801 1 wiring diagram. Warner electric cbc 801 1 power supply 6001 448 004. For 115 vac cbc 801 1 the hot line must be con nected to terminal 1. This shopping feature will continue to load items when the enter key is pressed. The cbc 801 will operate two units separately or simultaneously. The cbc 801 will operate two units separatelyor simultaneously. In order to navigate out of this carousel please use your heading shortcut key to navigate to the next or previous.
Octal socket is purchased separately. Cbc 801 series multi unit capacity the cbc 801 is a plug in power supply which is used with an octal socket. Connect the ac input to terminals 1. Mcs 103 1 power supply with single torque control. 115 vac 5060 hz 170 va output. Page 1 of 1 start over page 1 of 1.
Cancer and reproductive harm. The cbc 801 is a plug in power supply which is used with an octal socket purchased separately. Multi unit capacity the cbc 801 is a basic on off power supply that provides full voltage to a 90 volt clutch or brake and is activated by an external switch. This line measures 120 vac to conduit ground. P 0239 21 we installation operation manual for cbc 150 series clutchbrake controls. As shown in the connection diagram.
This is a floating type power supply. Fuse switch black hot red cbc 100 1 120 vac cbc 100 2 220240. For 120 vac cbc 801 1 the hot line must be connected to terminal 1. Customer between terminals 7 8 and 3 as shown in the connection diagram. Specifications cbc 801 1 cbc 801 2 part no. Radwell also repairs altra industrial motion cbc 801 1.
Used 2 from 5749 2500 shipping. 125 amp 90 vdc wleds parts. P 0239 17 we 819 0476 service installation instructions. Customers also shopped for. Models are available for either 120 vac or 220240 vac input. Page 2 introduction the warner electric cbc 801 series is a family of plug in clutchbrake controls designed for operation of all warner electric 90 volt dc clutches and brakes.
They should not however be used to directly power warner electric permanent. 6001 448 004 6001 448 006. The wiring connections are made at the socket. Buy new or surplus altra industrial motion cbc 801 1 clutchbrake power supply 8 pin 2 channel input. Page 1 cbc 801 series clutchbrake controls service installation instructions p 239 17 we 819 0476 an altra industrial motion company. P 0239 18 we 819 0478 installation and operation manual.
Connect the ac input to terminals 1 and 5. The cbc 100 and cbc 150 series are ul listed conduit box mounted controls for 90 volt clutches and brakes. Cbc 801 series clutchbrake controls.
