Timer delay adjustable from 2 to 45 seconds. Assa abloy does not supply hardware for mounting the door to the wall.
Productreview2019
Assa abloy ts 2t wiring diagram. Models ts 2t ts 3t ts 4t ts 5t ul file sa32686 terminal block wiring all models terminals designation notes jp3 power input power 12 to 24 volts ac or dc 60 ma maximum jp1 com common contact jp1 nc nc contact timed contacts rated 2a at 35vdc jp1 no no contact jp2. Locks door locks user manuals operating guides specifications. Use proper hardware best suited for each particular door installation. Push plates wave to open switches etc. Led illuminated push button 1224 vdc. Switch depth behind plate.
Make sure that 120v 60hz input power is turned off at facilitys main circuit breaker before proceeding with installation. Single gang 2 square push button spdt or dpdt. Assa abloy the global leader in door opening solutions securitron eeb2 eeb3n exit button with integrated timer installation and operating instructions 1. Your low energy operator can be configured in three variations to meet the standards. The model eeb3n is a spring loaded momentary. Est monday through friday.
View download of more than 646 assa abloy pdf user manuals service manuals operating guides. 12 red led operates on 12 or 24 vac or vdc. Model ts 2 2t provides an additional spdt momentary output model ts 2t 2 square led illuminated button and 12 red led operate on 12 or 24vdc. Prefer to speak with us. Today backed by the strength of assa abloy the global leader in door opening solutions alarm controls continues. 2 green square push button labeled push to exit swich mounted on single gang wallplate.
Single door controlled egress wiring diagram 01 single door digital entry wiring diagram 10 single door dk 26 with door prop alarm wiring diagram 15 single door dk1 11 xms dt 7 wiring diagram 20 single door dk 26 remote release wiring diagram 14 single door dk 26 unl 24 and dt 7 wiring diagram 18 single door dk 26 using the hard code to toggle lock off and on wiring diagram. It is the respon sibility of the door owner to ensure that the wall material is strong enough to support the forces of the door and all anchoring hardware. Some examples are shown below. Are available to activate the. Description the model eeb2 is a spring loaded momentary 2 square exit button mounted on a stainless steel single gang outlet box cover. 2 12 ul 294 listed.
Representatives are available 8 am. Spdt timed contacts rated 2a at 35vdc.
